GRM Series Specifications and Test Methods (2) (Note1) Typical Inspection
GRM Series Specifications and Test Methods (2) (Note1) Typical Inspection
1
(Note1) This Specifications and Test Methods indicates typical inspection.
Please refer to individual specifications (our product specifications or the approval sheet).
In case Non "*" is added in PNs table, please refer to GRM Series Specifications and Test Methods (1).
In case "*" is added in PNs table, please refer to GRM Series Specifications and Test Methods (2).
No.
1
Item
Specifications
B1, B3, F1: –25 to +85°C
R1, R7, C7, D7, E7: –55 to +125°C
C6, R6: –55 to +85°C
Test Method
Operating
Temperature
Range
Reference temperature: 25°C
(B1, B3, R1, F1: 20°C)
F5: –30 to +85°C
C8, D8: –55 to +105°C,
The rated voltage is defined as the maximum voltage which
may be applied continuously to the capacitor.
When AC voltage is superimposed on DC voltage, VP-P or VO-P
whichever is larger, should be maintained within the rated
voltage range.
2
Rated Voltage
See the previous pages.
,
3
4
Appearance
Dimensions
No defects or abnormalities
Visual inspection
Within the specified dimensions
Using calipers (GRM02 size is based on Microscope)
No failure should be observed when 250% of the rated voltage
is applied between the terminations for 1 to 5 seconds,
provided the charge/discharge current is less than 50mA.
5
6
Dielectric Strength No defects or abnormalities
The insulation resistance should be measured with a DC voltage
not exceeding the rated voltage at reference temperature and
75%RH max. and within 1 minutes of charging, provided the
charge/discharge current is less than 50mA.
Insulation
More than 50Ω · F
Resistance
Within the specified tolerance
*Table 1
GRM155
GRM185
GRM185
GRM188
GRM188
GRM188
GRM219
GRM219
B3/R6
B3/R6 1C/1A
C8/D7 1A
B3/R6 1C/1A
1A
124 to 105
105
The capacitance/D.F. should be measured at reference
temperature at the measuring frequency and voltage shown in
the table.
105
225
225
335
7
Capacitance
R7/C8
B3/R6
1A
1A
Nominal Capacitance Measuring Frequency Measuring Voltage
B3/R6 1C/1A 475, 106
CV10µF (10V min.)*
CV10µF (6.3V max.)
CG10µF
1±0.1kHz
1±0.1kHz
120±24Hz
1±0.1kHz
1.0±0.2Vrms
0.5±0.1Vrms
0.5±0.1Vrms
0.5±0.1Vrms
C8
1A
475
106
106
106
GRM21B B3/R6 1C/1A
GRM21B R7/C8 1A
GRM319 B3/R6 1C/1A
*For items in Table1
GRM188C80E106:
B1, B3, R1, R6*, R7*, C7, C8, E7, D7: 0.1 max.
C6: 0.125 max.
Perform a heat treatment at 150+0/-10°C for one hour and then
set for 24±2 hours at room temperature.
Dissipation Factor D8: 0.15 max.
8
(D.F.)
F1, F5: 0.2 max.
*GRM31CR71E106: 0.125 max.
GRM31CR6 0J/0G 107: 0.15 max.
B1, B3 : Within ±10% (–25 to +85°C)
The capacitance change should be measured after 5 min. at
each specified temp. stage.
F1
R6
: Within +30/–80% (–25 to +85°C)
: Within ±15% (–55 to +85°C)
The ranges of capacitance change compared with the
reference temperature value over the temperature ranges
shown in the table should be within the specified ranges.*
In case of applying voltage, the capacitance change should be
measured after 1 more min. with applying voltage in
equilibration of each temp. stage.
R1, R7 : Within ±15% (–55 to +125°C)
F5
: Within +22/–82% (–30 to +85°C)
: Within ±22% (–55 to +85°C)
No bias C6
C7
C8
D7
E7
D8
: Within ±22% (–55 to +125°C)
: Within ±22% (–55 to +105°C)
: Within +22/–33% (–55 to +125°C)
: Within +22/–56% (–55 to +125°C)
: Within +22/–33% (–55 to +105°C)
*GRM32DR60J226, GRM43 B1/B3/R6 0J/1A 336/476 only: 1.0±0.2Vrms
Step
Temperature (°C)
Applying Voltage (V)
25±2 (for R6, R7, C6, C7, C8, D7, D8, E7, F5
20±2 (for B1, B3, F1, R1)
)
1
–55±3 (for R1, R6, R7, C6, C7, C8, D7, D8, E7
–30±3 (for F5)
–25±3 (for B1, B3, F1)
)
2
3
4
Capacitance
Temperature
Characteristics
9
No bias
25±2 (for R6, R7, C6, C7, C8, D7, D8, E7, F5
20±2 (for B1, B3, F1, R1)
)
125±3 (for R1, R7, C7, D7, E7)
105±3 (for C8, D8)
85±3 (for B1, B3, F1, F5, R6, C6)
50% of
the Rated R1: Within +15/–40%
Voltage F1: Within +30/–95%
B1: Within +10/–30%
5
6
7
8
20±2 (for B1, F1, R1)
–55±3 (for R1)
–25±3 (for B1, F1)
20±2 (for B1, F1, R1)
125±3 (for R1)
85±3 (for B1, F1)
50% of the
rated voltage
•Initial measurement for high dielectric constant type
Perform a heat treatment at 150 +0/–10°C for one hour and
then set for 24±2 hours at room temperature.
Perform the initial measurement.
Continued on the following page.
