Chip Monolithic Ceramic Capacitors
Only for LCD Backlight Inverter Circuit
■ Features
e
g
e
1. Low-loss and suitable for high frequency circuits
2. Murata's original internal electrode structure
realizes high flash-over voltage.
3. A new monolithic structure for small, surface-
mountable devices capable of operating at high
voltage levels.
L
W
4. Sn-plated external electrodes realize good
solderability.
Dimensions (mm)
T
4.5 ±0.3 2.0 ±0.2 1.0 +0, - 0.3 0.3
Part Number
L
W
e min. g min.
5. Only for reflow soldering
GRM42A
2.9
6. The capacitors less than 22pF can be applied
maximum 4.0kV peak to peak at 100kHz or less
only for the ballast or the resonance usage in
the LCD backlight inverter circuit.
■ Applications
Ideal for use as the ballast in LCD backlight
inverter.
Do not use these products in any Automotive
Power train or Safety equipment including Battery
charger for Electric Vehicles and Plug-in Hybrid.
Only Murata products clearly stipulated as
"for Automotive use" on its catalog can be used
for automobile applications such as Power train and
Safety equipment.
11
Electrode g
Rated Voltage
(V)
TC Code
(Standard)
Capacitance
(pF)
Length L Width W Thickness T
Electrode e
(mm)
Part Number
min.
(mm)
(mm)
(mm)
(mm)
GRM42A5C3F050DW01L
GRM42A5C3F100JW01L
GRM42A5C3F120JW01L
GRM42A5C3F150JW01L
GRM42A5C3F180JW01L
GRM42A5C3F220JW01L
GRM42A5C3F270JW01L
GRM42A5C3F330JW01L
GRM42A5C3F390JW01L
GRM42A5C3F470JW01L
DC3150
DC3150
DC3150
DC3150
DC3150
DC3150
DC3150
DC3150
DC3150
DC3150
C0G (EIA)
C0G (EIA)
C0G (EIA)
C0G (EIA)
C0G (EIA)
C0G (EIA)
C0G (EIA)
C0G (EIA)
C0G (EIA)
C0G (EIA)
5.0 ±0.5pF
10 ±5%
12 ±5%
15 ±5%
18 ±5%
22 ±5%
27 ±5%
33 ±5%
39 ±5%
47 ±5%
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
4.5
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
2.9
0.3 min.
0.3 min.
0.3 min.
0.3 min.
0.3 min.
0.3 min.
0.3 min.
0.3 min.
0.3 min.
0.3 min.
176
