Specifications and Test Methods
Continued from the preceding page.
Specifications
No.
Item
Test Method
Appearance
No marking defects
Apply 120% of the rated voltage (150% of the rated voltage in
case of rated voltage: DC250V, 110% of the rated voltage in case
Within T15% (rated voltage: DC250V, DC630V)
Within T20% (rated voltage: DC1kV)
Capacitance
Change
W48
Y00
of rated voltage: DC1kV) for 1,000
hrs. at maximum
operating temperature T3D. Remove and let sit for 24T2 hrs. at
room condition*, then measure.
The charge/discharge current is less than 50mA.
#Pretreatment
D.F.
I.R.
0.05 max.
16 Life
CU0.01µF: More than 10MΩ • µF
CF0.01µF: More than 1,000MΩ
Apply test voltage for 60T5 min. at test temperature.
Remove and let sit for 24T2 hrs. at room condition*.
Dielectric
Strength
In accordance with item No.4
No marking defects
Within T15%
Appearance
Apply the rated voltage at 40T2D and relative humidity of 90 to
W24
Capacitance
Change
Humidity
95% for 500
hrs.
Y00
Loading
(Application:
DC250V,
DC630V
item)
Remove and let sit for 24T2 hrs. at room condition*, then
measure.
#Pretreatment
Apply test voltage for 60T5 min. at test temperature.
Remove and let sit for 24T2 hrs. at room condition*.
D.F.
I.R.
0.05 max.
17
CU0.01µF: More than 10MΩ • µF
CF0.01µF: More than 1,000MΩ
Dielectric
Strength
In accordance with item No.4
* "Room condition" Temperature: 15 to 35D, Relative humidity: 45 to 75%, Atmospheric pressure: 86 to 106kPa
