Chip Monolithic Ceramic Capacitors
for Bonding GMD Series
e
g
e
■ Features
1. Small chip size (LxWxT: 0.6x0.3x0.3, 1.0x0.5x0.5mm)
2. Available for Wire/Die bonding due to
Gold termination.
Outer electrode: Au
3. Suitable for Optical device for telecommunication,
IC packaging built-in.
L
W
■ Applications
1. Optical device for telecommunication
Dimensions (mm)
T
0.6±0.03 0.3±0.03 0.3±0.03 0.12 to 0.22 0.16
1.0±0.05 0.5±0.05 0.5±0.05 0.15 to 0.35 0.3
Part Number
L
W
e
g min.
GMD033
GMD155
2. IC, IC packaging built-in
8
127
