Chip Monolithic Ceramic Capacitors
Monolithic Microchip GMA Series
L
W
■ Features
1. Better micro wave characteristics
2. Suitable for by-passing
3. High density mounting
Outer electrode: Au plated
■ Applications
1. Optical device for telecommunication
2. IC, IC packaging built-in
3. Measuring equipment
Dimensions (mm)
W
Part Number
L
T
0.38 ±0.05
0.5 ±0.05
0.8 ±0.05
0.38 ±0.05
0.5 ±0.05
0.8 ±0.05
0.3 ±0.05
0.35 ±0.05
0.5 ±0.1
GMA0D3
GMA05X
GMA085
7
Capacitance Table
High Dielectric Constant Type X7R(R7)/X5R(R6) Characteristics
ex.X: T Dimension [mm]
X
0.38x0.38
0.5x0.5
(05)
<0202>
0.8x0.8
LxW
[mm]
(0D)
(08)
<015015>
<0303>
Rated Voltage
10
100
25
10
6.3
100
25
10
6.3
[Vdc]
(1A)
(2A)
(1E)
(1A)
(0J)
(2A)
(1E)
(1A)
(0J)
X7R
(R7)
X7R
(R7)
X5R
(R6)
X7R
(R7)
X5R
(R6)
TC
Capacitance
100pF(101)
150pF(151)
X
X
X
X
X
X
X
220pF(221)
330pF(331)
470pF(471)
680pF(681)
1000pF(102)
1500pF(152)
2200pF(222)
3300pF(332)
4700pF(472)
6800pF(682)
10000pF(103)
15000pF(153)
22000pF(223)
33000pF(333)
47000pF(473)
68000pF(683)
0.10µF(104)
0.47µF(474)
X
X
X
X
5
5
5
5
5
X
X
X
X
3
5
5
5
5
5
5
5
X
5
The part number code is shown in ( ) and Unit is shown in [ ].
< >: EIA [inch] Code
121
MURATA [ muRata ]
