MP1907―100V, 2.5A, HIGH FREQUENCY HALF-BRIDGE GATE DRIVER
TYPICAL PERFORMANCE CHARACTERISTICS (continued)
VDD =12V, VSS=VSW = 0V, TA= +25°C, unless otherwise noted.
Turn-on Propagation Delay
Turn-on Propagation Delay
Turn-off Protection Delay
20ns
20ns
18ns
IINH
2V/div.
INL
INH
2V/div.
2V/div.
DRVL
5V/div.
DRVH
5V/div.
DRVH
5V/div.
Turn-off Protection Delay
Drive Rise Time (1nF Load)
Drive Rise Time (1nF Load)
18ns
8ns
12ns
INL
2V/div.
DRVL
5V/div.
DRVH
5V/div.
DRVL
5V/div.
Drive Fall Time (1nF Load)
Drive Fall Time (1nF Load)
Input Signal Overlap Protection
5.2ns
5.2ns
INL & INH
5V/div.
DRVL
DRVH
5V/div.
5V/div.
DRVL
10V/div.
DRVH
10V/div.
