Freescale Semiconductor, Inc.
MSCAN Controller
Programmer’s Model of Control Registers
17.13.4 msCAN12 Bus Timing Register 0 (CBTR0)
Bit 7
SJW1
0
6
SJW0
0
5
BRP5
0
4
BRP4
0
3
BRP3
0
2
BRP2
0
1
BRP1
0
Bit 0
BRP0
0
CBTR0
$0102
R
W
RESET
SJW1, SJW0 — Synchronization Jump Width
The synchronization jump width defines the maximum number of time
quanta (Tq) clock cycles by which a bit may be shortened, or
lengthened, to achieve resynchronization on data transitions on the
bus (see Table 17-5).
Table 17-5. Synchronization jump width
SJW1
SJW0
Synchronization jump width
1 Tq clock cycle
0
0
1
1
0
1
0
1
2 Tq clock cycles
3 Tq clock cycles
4 Tq clock cycles
BRP5 – BRP0 — Baud Rate Prescaler
These bits determine the time quanta (Tq) clock, which is used to
build up the individual bit timing, according to Table 17-6.
Table 17-6. Baud rate prescaler
Prescaler value
BRP5
BRP4
BRP3
BRP2
BRP1
BRP0
(P)
0
0
0
0
:
0
0
0
0
:
0
0
0
0
:
0
0
0
0
:
0
0
1
1
:
0
1
0
1
:
1
2
3
4
:
:
:
:
:
:
:
:
1
1
1
1
1
1
64
NOTE: The CBTR0 register can only be written if the SFTRES bit in CMCR0 is
set.
68HC(9)12D60 — Rev 4.0
MOTOROLA
Advance Information
307
