MSCAN Controller
Programmer’s Model of Control Registers
SFTRES— SOFT_RESET
When this bit is set by the CPU, the msCAN12 immediately enters the
SOFT_RESET state. Any ongoing transmission or reception is
aborted and synchronisation to the bus is lost.
The following registers will go into and stay in the same state as out
of hard reset: CMCR0, CRFLG, CRIER, CTFLG, CTCR.
The registers CMCR1, CBTR0, CBTR1, CIDAC, CIDAR0–3,
CIDMR0–3 can only be written by the CPU when the msCAN12 is in
SOFT_RESET state. The values of the error counters are not affected
by SOFT_RESET.
When this bit is cleared by the CPU, the msCAN12 will try to
synchronize to the CAN bus: If the msCAN12 is not in BUSOFF state
it will be synchronized after 11 recessive bits on the bus; if the
msCAN12 is in BUSOFF state it continues to wait for 128 occurrences
of 11 recessive bits.
Clearing SFTRES and writing to other bits in CMCR0 must be in
separate instructions.
0 = Normal operation
1 = msCAN12 in SOFT_RESET state.
17.13.3 msCAN12 Module Control Register 1 (CMCR1).
Bit 7
0
6
0
5
0
4
0
3
0
2
LOOPB
0
1
WUPM
0
Bit 0
CLKSRC
0
CMCR1
$0101
R
W
RESET
0
0
0
0
0
LOOPB — Loop Back Self Test Mode
When this bit is set the msCAN12 performs an internal loop back
which can be used for self test operation: the bit stream output of the
transmitter is fed back to the receiver internally. The RxCAN input pin
is ignored and the TxCAN output goes to the recessive state (1). The
msCAN12 behaves as it does normally when transmitting and treats
its own transmitted message as a message received from a remote
68HC(9)12D60 — Rev 4.0
MOTOROLA
Advance Information
MSCAN Controller
305
