Electrical Characteristics
6 Electrical Characteristics
•
•
•
•
A = 100% Tested
B = 100% Correlation tested
C = Characterized on samples
D = Design parameter
6.1 Specification Conditions
Unless otherwise stated: Vcc = 5.0V, T amb. = 25°C.Video input 1Vp-p, 10 step greyscale. RF inputs /
outputs into 75Ω load. SPECIFICATIONS ONLY VALID FOR ENVELOPE DEMODULATION
Power Supply Parameters
Min Typ Max Unit
Notes
Type
Operating Supply Voltage range
Total Supply Current
4.5
40
3
5.0
47
5
5.5
55
7
V
B
A
A
mA All sections active
mA PSave/LO=LO
Total Standby Mode Supply Current
DC Parameter
Min Typ Max Unit
Type
Threshold voltage level on pins CHS, PSS, SFS, PSave/LO
2.1
10
1
V
C
A
A
A
D
7
0.7
60
1
12
µA
µA
µA
KΩ
Sound Comparator Charge Pump Current: During locking
When locked
1.5
RF Comparator Charge Pump Current
100 150
Crystal Oscillator Stability - negative resistance
-
-
Logic Output Port: Saturation voltage @ I=15mA
Leakage current
-
-
210 300
mV
uA
A
A
-
1
