MITSUBISHI MICROCOMPUTERS
3827 Group
SINGLE-CHIP 8-BIT CMOS MICROCOMPUTER
Table 5 List of I/O port function (2)
Pin
Name
Input/Output
I/O Format
Non-Port Function
Related SFRS
Diagram No.
P60/SIN2/AN0
Port P6
Input/
A-D conversion input
Serial I/O2 function I/O
A-D control register
Serial I/O2 control
register
(17)
CMOS compatible input
level
CMOS 3-state output
output,
individnal
bits
P61/SOUT2/
AN1
(18)
(19)
P62/SCLK21/
AN2
P63/SCLK22 /
AN3
(20)
(16)
A-D conversion input
A-D control register
P64/AN4–
P67/AN7
P70/INT0
Port P7
Input
CMOS compatible input
level
External interrupt input
Interrupt edge
selection register
(23)
(13)
P71–P77
Input/
CMOS compatible input
level
output,
individnal
bits
N-channel open-drain
output
COM0–COM3
SEG0–SEG17
Common
Segment
Output
Output
LCD common output
LCD segment output
LCD mode register
(21)
(22)
Notes1: How to use double-function ports as function I/O ports, refer to the applicable sections.
2: Make sure that the input level at each pin is either 0 V or VCC during execution of the STP instruction. When an input level is at an intermediate po-
tential, a current will flow VCC to VSS through the input-stage gate.
13
