SINGLE-CHIP 8-BIT CMOS MICROCOMPUTER with CLOSED CAPTION DECODER
and ON-SCREEN DISPLAY CONTROLLER
EXOSD mode
16 dots
OSD mode
16 dots
Character
font area
1 dot width of border
1 dot width of border
1 dot width of border
1 dot width of border
Fig. 72. Border area
7
0
Border color register
(FC : address 021B16)
Border color R control bit
0 : No output
1 : Output
Border color G control bit
0 : No output
1 : Output
Border color B control bit
0 : No output
1 : Output
Border color I1 control bit
0 : No output
1 : Output
Character boundary Character boundary Character boundary
B
A
B
Border color I2 control bit
0 : No output
1 : Output
Fig. 73. Border priority
Fig. 74. Structure of border color register
