Reset
Reset
There are two kinds of resets; hardware and software. In both cases, operation is the same after the reset.
(See “Software Reset” for details of software resets.) This section explains on hardware resets.
When the supply voltage is in the range where operation is guaranteed, a reset is effected by holding the
reset pin level “L” (0.2VCC max.) for at least 20 cycles. When the reset pin level is then returned to the “H”
level while main clock is stable, the reset status is cancelled and program execution resumes from the
address in the reset vector table.
Figure 1.6.1 shows the example reset circuit. Figure 1.6.2 shows the reset sequence.
5V
4.0V
V
CC
0V
5V
VCC
RESET
RESET
0V
0.8V
Example when VCC = 5V
.
Figure 1.6.1. Example reset circuit
X
IN
More than 20 cycles are needed
BCLK 24cycles
Microprocessor
mode BYTE = “H”
RESET
BCLK
Address
RD
Content of reset vector
FFFFC16
FFFFD16
FFFFE16
WR
CS0
Microprocessor
mode BYTE = “L”
Content of reset vector
FFFFC16
FFFFE16
Address
RD
WR
CS0
Single chip
mode
FFFFC16
Content of reset vector
Address
FFFFE16
Figure 1.6.2. Reset sequence
