SDA 9380 - B21
Preliminary Data Sheet
Characteristics (assuming recommended operating conditions)
Parameter
Symbol Min
Nom Max
Unit Remark
Gain error
-5%
5%
*)
*)
*)
INL
-0.2%
-0.1%
0.2%
0.1%
DNL
*) input range = 100...900
DAC Output VD+, VD-
DAC resolution
14
bit
linear range:
1500...15000
DAC output LOW (VD-)
DAC output HIGH (VD-)
DAC output LOW (VD-) - (VD+)
DAC output HIGH (VD-) - (VD+)
Load capacitance
Output load
0.62
2.6
V
input data = 1500
input data = 15000
input data = 1500
input data = 15000
V
-1.90
1,96
30
V
V
pF
20
kOhm
Zero error
-1%
-5%
-0.5%
1%
(VD-)-(VD+)=0V, *)
Gain error
5%
*)
*)
INL
0.5%
DNL
monotonous
guaranteed by
design
*) input range = 1500...15000
Reference Output VREFH
Output voltage
1.568
0
1.6
1.632
V
tolerance +-2%
Open Drain Output HD
Output Low level
VOL
VOH
1
V
V
I = 8 mA
O
Maximum Voltage
5.5
Output H35K
Output Low level
VOL
VOH
fTH1
0.4
V
IO = 1 mA
IO = -1 mA
see 11.1
see 11.1
Output High level
2.4
V
Positive-going threshold of fHSYNC
33.9
33.3
0.6
kHz
kHz
kHz
Negative-going threshold of fHSYNC fTH2
Hysteresis
fTH1 - fTH2
Micronas
9-52
2001-01-29
