SDA 9380 - B21
Preliminary Data Sheet
System description
A
1
2
15
16
17
18
19
20
21
22
23
24
25
HSYNC
VSYNC
1 line
VD-
start of even field
start of odd field
R
R
G
B
VBL
22 lines
odd field
(default:
BSE=0,
VBS=0,
VBE=0)
R
G
B
B
even field
2 lines
G
B
VBL
24 lines
odd field
(BSE=0,
VBS=2,
VBE=0)
R
G
even field
R
G
B
VBL
20 lines
odd field
(BSE=1,
RPP=1,
VBS=0,
VBE =1)
R
G
B
even field
Internal vertical blanking pulse VBL when JMP = 0 and number of lines per field = constant
b) Description of VBL when JMP= 1
Start of VBL = VBS lines before the first complete line of the next field
(def. value 0)
if BSE = 0
end of VBL = end of line (VBE + 29) (odd field)
width of VBL = (VBS + VBE + 29) lines (odd field)(def. value 29)
if BSE = 1
end of VBL = end of line (RPP + VBE + 25) (odd field)
width of VBL = (VBS + RPP + VBE + 25) lines (odd field)
Note! If JMP = 1 the number of lines between the last ref. pulse and the end of
VBL is defined by VBE in the range of 7 (VBE = 0) to 14 (VBE = 7).
