PIC18CXX2
21.4.2 TIMING CONDITIONS
The temperature and voltages specified in Table 21-3
apply to all timing specifications unless otherwise
noted. Figure 21-4 specifies the load conditions for the
timing specifications.
TABLE 21-3: TEMPERATURE AND VOLTAGE SPECIFICATIONS - AC
Standard Operating Conditions (unless otherwise stated)
Operating temperature -40°C ≤ TA ≤ +85°C for industrial
AC CHARACTERISTICS
-40°C ≤ TA ≤ +125°C for extended
Operating voltage VDD range as described in DC spec Section 21.1 and Section 21.2.
LC parts operate for industrial temp’s only.
FIGURE 21-4: LOAD CONDITIONS FOR DEVICE TIMING SPECIFICATIONS
Load condition 1
Load condition 2
VDD/2
CL
RL
Pin
VSS
CL
Pin
RL = 464Ω
CL = 50 pF for all pins except OSC2/CLKOUT
VSS
and including D and E outputs as ports
DS39026B-page 252
Preliminary
7/99 Microchip Technology Inc.
