PIC18CXX2
21.2
DC Characteristics: PIC18LCXX2 (Industrial) (cont’d)
Standard Operating Conditions (unless otherwise stated)
Operating temperature -40°C ≤ TA ≤ +85°C for industrial
DC CHARACTERISTICS
Param Symbol
No.
Characteristic
Min Typ Max Units
Conditions
Power-down Current(3)
IPD
D020
—
—
—
<2.5
—
—
5
36
µA VDD = 2.5V, -40°C to +85°C
µA VDD = 5.5V, -40°C to +85°C
TBD µA VDD = 2.5V, 25°C
Module Differential
Current
D022
∆IWDT
Watchdog Timer
—
—
—
—
—
—
12
25
µA VDD = 2.5V
µA VDD = 5.5V
TBD µA VDD = 2.5V, 25°C
50 µA VDD = 5.5V
TBD µA VDD = 2.5V, 25°C
50 µA VDD = 2.5V
TBD µA VDD = 2.5V, 25°C
µA VDD = 2.5V
TBD µA VDD = 2.5V, 25°C
D022A ∆IBOR
D022B ∆ILVD
Brown-out Reset
—
—
—
—
Low Voltage Detect
—
—
—
—
D025
∆IOSCB Timer1 oscillator
—
—
—
—
3
Legend: Shading of rows is to assist in readability of the table.
Note 1: This is the limit to which VDD can be lowered in SLEEP mode or during a device reset without losing RAM
data.
2: The supply current is mainly a function of the operating voltage and frequency. Other factors, such as I/O pin
loading and switching rate, oscillator type, internal code execution pattern and temperature, also have an
impact on the current consumption.
The test conditions for all IDD measurements in active operation mode are:
OSC1 = external square wave, from rail to rail; all I/O pins tristated, pulled to VDD
MCLR = VDD; WDT enabled/disabled as specified.
3: The power-down current in SLEEP mode does not depend on the oscillator type. Power-down current is
measured with the part in SLEEP mode, with all I/O pins in hi-impedance state and tied to VDD and VSS, and
all features that add delta current disabled (such as WDT, Timer1 Oscillator, BOR, ...).
4: For RC osc configuration, current through Rext is not included. The current through the resistor can be esti-
mated by the formula Ir = VDD/2Rext (mA) with Rext in kOhm.
DS39026B-page 246
Preliminary
7/99 Microchip Technology Inc.
