PIC16F87/88
18.3 DC Characteristics: Internal RC Accuracy
PIC16F87/88 (Industrial)
PIC16LF87/88 (Industrial)
PIC16LF87/88
Standard Operating Conditions (unless otherwise stated)
Operating temperature -40°C ≤ TA ≤ +85°C for industrial
(Industrial)
PIC16F87/88
Standard Operating Conditions (unless otherwise stated)
Operating temperature -40°C ≤ TA ≤ +85°C for industrial
(Industrial)
Param
No.
Device
Min
Typ
Max
Units
Conditions
(1)
INTOSC Accuracy @ Freq = 8 MHz, 4 MHz, 2 MHz, 1 MHz, 500 kHz, 250 kHz, 125 kHz
PIC16LF87/88
PIC16F87/88
-2
-5
±1
—
—
±1
—
—
2
5
%
%
%
%
%
%
25°C
VDD = 2.7-3.3V
VDD = 2.7-3.3V
VDD = 2.7-3.3V
VDD = 4.5-5.5V
VDD = 4.5-5.5V
VDD = 4.5-5.5V
-10°C - +85°C
-40°C - +85°C
25°C
-10
-2
10
2
-5
5
-10°C - +85°C
-40°C - +85°C
-10
10
(2)
INTRC Accuracy @ Freq = 31 kHz
PIC16LF87/88
PIC16F87/88
26.562
26.562
—
—
35.938
35.938
kHz
kHz
-40°C - +85°C
-40°C - +85°C
VDD = 2.7-3.3V
VDD = 4.5-5.5V
Legend:
Shading of rows is to assist in readability of the table.
Note 1: Frequency calibrated at 25°C. OSCTUNE register can be used to compensate for temperature drift.
2: INTRC frequency after calibration.
DS30487B-page 172
Preliminary
2003 Microchip Technology Inc.
