PIC16C55X(A)
FIGURE 7-14: WATCHDOG TIMER BLOCK DIAGRAM
From TMR0 Clock Source
(Figure 6-6)
0
M
U
X
Postscaler
8
1
Watchdog
Timer
•
PS<2:0>
To TMR0 (Figure 6-6)
PSA
8 - to -1 MUX
PSA
WDT
Enable Bit
•
1
0
MUX
WDT
Time-out
Note: T0SE, T0CS, PSA, PS0-PS2 are bits in the OPTION register.
FIGURE 7-15: SUMMARY OF WATCHDOG TIMER REGISTERS
Address
Name
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
2007h
81h
Config. bits
OPTION
—
+
CP1
CP0
PWRTE
PSA
WDTE
PS2
FOSC1
PS1
FOSC0
PS0
RBPU
INTEDG
T0CS
T0SE
Legend: Shaded cells are not used by the Watchdog Timer.
— = Unimplemented location, read as ‘0’.
+ = Reserved for future use.
