REGISTER 25-2: CPSCON1: CAPACITIVE SENSING CONTROL REGISTER 1
U-0
—
U-0
—
U-0
—
R/W-0/0
R/W-0/0
R/W-0/0
R/W-0/0
R/W-0/0
CPSCH<4:0>
bit 7
bit 0
Legend:
R = Readable bit
u = Bit is unchanged
‘1’ = Bit is set
W = Writable bit
x = Bit is unknown
‘0’ = Bit is cleared
U = Unimplemented bit, read as ‘0’
-n/n = Value at POR and BOR/Value at all other Resets
bit 7-5
bit 4-0
Unimplemented: Read as ‘0’
CPSCH<4:0>: Capacitive Sensing Channel Select bits
If CPSON = 0:
These bits are ignored. No channel is selected.
If CPSON = 1:
00000= channel 0, (CPS0)
00001= channel 1, (CPS1)
00010= channel 2, (CPS2)
00011= channel 3, (CPS3)
00100= channel 4, (CPS4)
00101= channel 5, (CPS5)
00110= channel 6, (CPS6)
00111= channel 7, (CPS7)
01000= channel 8, (CPS8)
01001= channel 9, (CPS9)
01010= channel 10, (CPS10)
01011= channel 11, (CPS11)
01100= channel 12, (CPS12)
01101= channel 13, (CPS13)
01110= channel 14, (CPS14)
01111= channel 15, (CPS15)
10000= channel 16, (CPS16)
10001= Reserved. Do not use.
.
.
.
11111= Reserved. Do not use.
