PIC16C62B/72A
Pin Diagrams
SDIP, SOIC, SSOP, Windowed CERDIP
MCLR/VPP
RA0
• 1
2
3
4
5
28
27
26
25
24
RB7
RB6
RB5
RB4
RB3
RA1
RA2
RA3
RA4/T0CKI
RA5/SS
6
7
8
23
22
21
20
19
18
17
16
15
RB2
RB1
RB0/INT
VDD
VSS
RC7
RC6
RC5/SDO
RC4/SDI/SDA
VSS
OSC1/CLKIN
OSC2/CLKOUT
RC0/T1OSO/T1CKI
RC1/T1OSI
9
10
11
12
13
14
RC2/CCP1
RC3/SCK/SCL
Key Features
PICmicro™ Mid-Range Reference Manual
(DS33023)
PIC16C62B
PIC16C72A
Operating Frequency
Resets (and Delays)
Program Memory (14-bit words)
Data Memory (bytes)
Interrupts
DC - 20 MHz
DC - 20 MHz
POR, BOR (PWRT, OST)
POR, BOR (PWRT, OST)
2K
2K
128
128
7
8
I/O Ports
Ports A,B,C
Ports A,B,C
Timers
3
3
Capture/Compare/PWM modules
Serial Communications
8-bit Analog-to-Digital Module
1
1
SSP
SSP
—
5 input channels
