Table 17-2. Recommended Maximum Receiver Baud Rate Error for Normal Speed Mode
(U2Xn = 0)
D
Recommended Max
Receiver Error (%)
# (Data+Parity Bit)
R
slow (%)
93.20
94.12
94.81
95.36
95.81
96.17
Rfast (%)
106.67
105.79
105.11
104.58
104.14
103.78
Max Total Error (%)
+6.67/-6.8
5
6
3.0
2.5
2.0
2.0
1.5
1.5
+5.79/-5.88
+5.11/-5.19
+4.58/-4.54
+4.14/-4.19
+3.78/-3.83
7
8
9
10
Table 17-3. Recommended Maximum Receiver Baud Rate Error for Double Speed Mode
(U2Xn = 1)
D
Recommended Max
Receiver Error (%)
# (Data+Parity Bit)
Rslow (%)
94.12
94.92
95.52
96.00
96.39
96.70
Rfast (%)
105.66
104.92
104,35
103.90
103.53
103.23
Max Total Error (%)
+5.66/-5.88
5
6
2.5
2.0
1.5
1.5
1.5
1.0
+4.92/-5.08
7
+4.35/-4.48
8
+3.90/-4.00
9
+3.53/-3.61
10
+3.23/-3.30
The recommendations of the maximum receiver baud rate error was made under the assump-
tion that the Receiver and Transmitter equally divides the maximum total error.
There are two possible sources for the receivers baud rate error. The Receiver’s system clock
(XTAL) will always have some minor instability over the supply voltage range and the tempera-
ture range. When using a crystal to generate the system clock, this is rarely a problem, but for a
resonator the system clock may differ more than 2ꢀ depending of the resonators tolerance. The
second source for the error is more controllable. The baud rate generator can not always do an
exact division of the system frequency to get the baud rate wanted. In this case an UBRRn value
that gives an acceptable low error can be used if possible.
17.8 Multi-processor Communication Mode
Setting the Multi-processor Communication mode (MPCMn) bit in UCSRnA enables a filtering
function of incoming frames received by the USART Receiver. Frames that do not contain
address information will be ignored and not put into the receive buffer. This effectively reduces
the number of incoming frames that has to be handled by the CPU, in a system with multiple
MCUs that communicate via the same serial bus. The Transmitter is unaffected by the MPCMn
setting, but has to be used differently when it is a part of a system utilizing the Multi-processor
Communication mode.
