93AA66A/B/C, 93LC66A/B/C, 93C66A/B/C
The DO pin indicates the READY/BUSY status of the
device, if CS is brought high after a minimum of 250 ns
2.8
WRITE
The WRITEinstruction is followed by 8 bits (If ORG is
low or A-version devices) or 16 bits (If ORG pin is high
or B-version devices) of data which are written into the
specified address. For 93AA66A/B/C and 93LC66A/B/C
devices, after the last data bit is clocked into DI, the
falling edge of CS initiates the self-timed auto-erase and
programming cycle. For 93C66A/B/C devices, the self-
timed auto-erase and programming cycle is initiated by
the rising edge of CLK on the last data bit.
low (TCSL). DO at logical ‘0’ indicates that programming
is still in progress. DO at logical ‘1’ indicates that the
register at the specified address has been written with
the data specified and the device is ready for another
instruction.
Note:
Issuing a Start bit and then taking CS low
will clear the READY/BUSY status from
DO.
FIGURE 2-8:
WRITE TIMING FOR 93AA AND 93LC DEVICES
TCSL
CS
CLK
DI
0
1
1
An
A0
Dx
D0
•••
•••
TSV
TCZ
HIGH-Z
BUSY
READY
DO
HIGH-Z
Twc
FIGURE 2-9:
WRITE TIMING FOR 93C DEVICES
TCSL
CS
CLK
DI
0
1
1
An
A0
Dx
D0
•••
•••
TSV
TCZ
HIGH-Z
BUSY
READY
DO
HIGH-Z
Twc
2003 Microchip Technology Inc.
DS21795B-page 9
