Shutdown Mode
Holding
SHDN
low puts the IC into its 4µA shutdown
mode.
SHDN
is logic input with a threshold of about 1V
(the V
TH
of an internal N-channel MOSFET). For auto-
matic start-up, bypass
SHDN
to GND with a 0.01µF
capacitor and connect it to V+ through a 220kΩ resistor.
Output Undervoltage Shutdown Protection
(MAX1630/MAX1631/MAX1632)
The output undervoltage lockout circuit is similar to
foldback current limiting, but employs a timer rather
than a variable current limit. Each SMPS has an under-
voltage protection circuit that is activated 6144 clock
cycles after the SMPS is enabled. If either SMPS output
is under 70% of the nominal value, both SMPSs are
latched off and their outputs are clamped to ground by
the synchronous rectifier MOSFETs (see
Output
Overvoltage Protection
section). They won’t restart until
SHDN
or RUN/ON3 is toggled, or until V+ power is
cycled below 1V. Note that undervoltage protection can
make prototype troubleshooting difficult, since you
have only 20ms or 30ms to figure out what might be
wrong with the circuit before both SMPSs are latched
off. In extreme cases, it may be useful to substitute the
MAX1633/MAX1634/MAX1635 into the prototype
breadboard until the prototype is working properly.
MAX1630–MAX1635
Power-Up Sequencing
and ON/
OFF
Controls
Start-up is controlled by RUN/ON3 and TIME/ON5 in
conjunction with SEQ. With SEQ tied to REF, the two
control inputs act as separate ON/OFF controls for
each supply. With SEQ tied to VL or GND, RUN/ON3
becomes the master ON/OFF control input and
TIME/ON5 becomes a timing pin, with the delay
between the two supplies determined by an external
capacitor. The delay is approximately 800µs/nF. The
+3.3V supply powers-up first if SEQ is tied to VL, and
the +5V supply is first if SEQ is tied to GND. When driv-
ing TIME/ON5 as a control input with external logic,
always place a resistor (>1kΩ) in series with the input.
This prevents possible crowbar current due to the inter-
nal discharge pull-down transistor, which turns on in
standby mode and momentarily at the first power-up or
in shutdown mode.
Output Overvoltage Protection
(MAX1630/MAX1631/MAX1632)
Both SMPS outputs are monitored for overvoltage. If
either output is more than 7% above the nominal regu-
lation point, both low-side gate drivers (DL_) are
latched high until
SHDN
or RUN/ON3 is toggled, or until
V+ power is cycled below 1V. This action turns on the
synchronous rectifiers with 100% duty, in turn rapidly
discharging the output capacitors and forcing both
SMPS outputs to ground. The DL outputs are also kept
high whenever the corresponding SMPS is disabled,
and in shutdown if VL is sustained.
RESET
Power-Good Voltage Monitor
The power-good monitor generates a system
RESET
sig-
nal. At first power-up,
RESET
is held low until both the
3.3V and 5V SMPS outputs are in regulation. At this point,
an internal timer begins counting oscillator pulses, and
RESET
continues to be held low until 32,000 cycles have
elapsed. After this timeout period (107ms at 300kHz or
160ms at 200kHz),
RESET
is actively pulled up to VL. If
SEQ is tied to REF (for separate ON3/ON5 controls), only
the 3.3V SMPS is monitored—the 5V SMPS is ignored.
Table 4. Operating Modes
SHDN
Low
High
High
High
High
High
High
High
High
SEQ
X
Ref
Ref
Ref
Ref
GND
GND
VL
VL
RUN/ON3
X
Low
High
Low
High
Low
High
Low
High
TIME/ON5
X
Low
Low
High
High
Timing capacitor
Timing capacitor
Timing capacitor
Timing capacitor
MODE
Shutdown
Standby
Run
Run
Run
Standby
Run
Standby
Run
DESCRIPTION
All circuit blocks turned off. Supply current = 4µA.
Both SMPSs off. Supply current = 30µA.
3.3V SMPS enabled/5V off
5V SMPS enabled/3.3V off
Both SMPSs enabled
Both SMPSs off. Supply current = 30µA.
Both SMPSs enabled. 5V enabled before 3.3V.
Both SMPSs off. Supply current = 30µA.
Both SMPSs enabled. 3.3V enabled before 5V.
X = Don’t Care
