DS1624
Access Memory [17h]
This command instructs the DS1624 to access its E2 memory. After issuing this command, the next data
byte is the value of the word address to be accessed. See OPERATION–MEMORY section for detailed
explanations of the use of this protocol and data format following it.
Access Config [ACh]
If R/
W
is “0”, this command writes to the configuration register. After issuing this command, the next
data byte is the value to be written into the configuration register. If R/
the value stored in the configuration register.
W
is “1”, the next data byte read is
Read Temperature [AAh]
This command reads the last temperature conversion result. The DS1624 will send two bytes in the
format described earlier, which are the contents of this register.
Start Convert T [EEh]
This command begins a temperature conversion. No further data is required. In one–shot mode the
temperature conversion will be performed and then the DS1624 will remain idle. In continuous mode this
command will initiate continuous conversions.
Stop Convert T [22h]
This command stops temperature conversion. No further data is required. This command may be used to
halt a DS1624 in continuous conversion mode. After issuing this command, the current temperature
measurement will be completed then the DS1624 will remain idle until a Start Convert T is issued to
resume continuous operation.
DS1624 COMMAND SET Table 3
2-WIRE BUS
DATA AFTER
ISSUING
INSTRUCTION
DESCRIPTION
PROTOCOL PROTOCOL
NOTES
TEMPERATURE CONVERSION COMMANDS
Read
Temperature
Reads last converted temperature
value from temperature register.
AAh
<read 2 bytes
data>
Start Convert T Initiates temperature conversion.
Stop Convert T Halts temperature conversion.
EEh
22h
idle
idle
1
1
THERMOSTAT COMMANDS
Access Memory Reads or writes to 256-byte
17h
<write data>
<write data>
2
2
EEPROM memory.
Access Config
Reads or writes configuration data
to configuration register.
ACh
NOTES:
1. In continuous conversion mode a Stop Convert T command will halt continuous conversion. To
restart, the Start Convert T command must be issued. In one–shot mode a Start Convert T command
must be issued for every temperature reading desired.
2. Writing to the E2 typically requires 10 ms at room temperature. After issuing a write command, no
further reads or writes should be requested for at least 10 ms.
10 of 20
