METRIC
Dimensions are
millimeters over inches
Ribbon Cable Interconnect Solutions
MPaigcreoH-MeaadT_c1h2M_HineilavtCudreBdCo(Cnonnteincuteodr) System —
Male-on-Board Connector
A
5.00
[.197]
A
A
This male connector version
is designed to be soldered
onto PC Boards with a nom-
inal thickness of 1.6 mm.
B
2.54
[.100]
1.27
[.050]
The solder legs are
indented for firm retention of
the connector in the
PC Board.
6.75
[.266]
The connector housing
features a polarizing pin
on one end for proper
orientation of this connector
version.
7.10
[.280]
Section A-A
0.80
[.031]
2.54
[.100]
1.27
[.050]
2.54
[.100]
Typical Hole Pattern
Not Solder Side Shown
Notes:
1. To enable automatic Pick & Placement, connectors are always packed in
embossed tape according EIA481 specification.
2. Standard packaging quantity is 900 pcs on a reel with a diameter of 330 mm.
3. Connectors are supplied with or without a feature for vacuum Pick & Placement.
4. For this connector no additional solder hold down is required.
Dimensions (mm)
Part Numbers
2500 Connectors/Reel
No. of Positions
Mates with:
X-338095-X
X-215083-X
X-215464-X
X-338728-X
A
B
250 Connectors/Box
7-215464-4
7-215464-6
7-215464-8
8-215464-0
8-215464-2
8-215464-4
8-215464-6
8-215464-8
9-215464-0
4
3.81
8.2
215464-4
215464-6
6
6.35
10.7
13.3
15.8
18.3
20.8
23.4
25.9
28.4
8
8.89
215464-8
10
12
14
16
18
20
11.43
13.97
16.51
19.05
21.59
24.13
1-215464-0
1-215464-2
1-215464-4
1-215464-6
1-215464-8
2-215464-0
37
Catalog 82012
Revised 4-12
Dimensions are shown for
Dimensions are in inches
and millimeters unless
otherwise specified.
