METRIC
Dimensions are
millimeters over inches
Ribbon Cable Interconnect Solutions
Micro-MaTch Miniature Connector System —
Female-on-Board Connector Surface Mount Device (SMD)
Tape for Vacuum P&P
1.90
[.075]
1.27
[.050]
This SMD connector version
is designed for standard
reflow and infrared solder
processes (“FULL SMD”).
Polarization is accom-
plished by the housing,
therefor no polarization
holes in the PC Board are
required.
A=(N-1)*1.27
0.5B-2.5
5.0
[.197]
5.0
[.197]
The contact is designed with
an additional spring to com-
pensate for differences in
thermal expansion between
housing and PCB. Due to
this feature, tension on
7.0
[.276]
B
A
2.54
[.100]
solder joints is prevented.
5.0
[.197]
1.50
[.059]
3.00 Minimum
[.118] Solder Path Length
1.50
[.059]
Recommended
PCB Layout
Top View
Notes:
1. To enable automatic Pick & Placement, connectors are always packed in embossed
tape according EIA481 specification.
2. Standard packaging quantity is 900 pcs on a reel with a diameter of 330 mm.
3. Connectors are supplied with or without a feature for vacuum Pick & Placement.
4. For this connector no additional solder hold down is required.
Mates with:
X-338095-X
X-215083-X
X-215464-X
X-338728-X
Dimensions (mm)
Part Numbers
2500 Connectors/Reel
No. of Positions
A
B
250 Connectors/Box
7-188275-4
7-188275-6
7-188275-8
8-188275-0
8-188275-2
8-188275-4
8-188275-6
8-188275-8
9-188275-0
4
3.81
7.1
188275-4
188275-6
6
6.35
9.7
8
8.89
12.2
14.7
17.3
19.8
22.4
24.9
27.4
188275-8
10
12
14
16
18
20
11.43
13.97
16.51
19.05
21.59
24.13
1-188275-0
1-188275-2
1-188275-4
1-188275-6
1-188275-8
2-188275-0
36
Catalog 82012
Revised 4-12
Dimensions are shown for
Dimensions are in inches
and millimeters unless
otherwise specified.
