METRIC
Dimensions are
millimeters over inches
Ribbon Cable Interconnect Solutions
Micro-MaTch Miniature Connector System —
Female-on-Board Connector, Top Entry
1.5
[.059]
5.1
[.200]
Max.
4.0
[.157]
This connector version
incorporates the patented
Micro-MaTch contact spring
system and is designed to
be soldered onto PC
Boards with a nominal thick-
ness of 1.6 mm.
1.9
[.074]
3.1
[.122]
The solder legs are
1.27
indented, providing firm
retention of the connector
before and during the
soldering operations.
[.050]
A
B Max.
As polarization is accom-
plished directly between the
Micro-MaTch male connec-
tors and the PC Board, this
top entry female connector
does not have any polariz-
ing features. Therefore, the
orientation of the connector
on the PC Board is irrele-
vant.
1.40
2.54
1.80
[.071]
[.055]
[.100]
1.27
[.050]
1.50
[.059]
Hole for
Polarization Pin
0.80
[.031]
2.54
[.100]
Typical Hole Pattern
Not Solder Side Shown
Notes:
1. Connectors are always sideways mounted onto an adhesive tape.
2. Standard packaging quantity is 2500 connectors on a reel with a diameter of 600 mm.
3. At additional charge a special packaging option is available: 250 connectors on
a reel with a diameter of 250 mm, packed in a dedicated dispenser box.
Mates with:
X-338095-X
X-215083-X
X-215464-X
X-338728-X
Dimensions (mm)
Part Numbers
2500 Connectors/Reel
No. of Positions
A
B
250 Connectors/Box
7-215079-4
7-215079-6
7-215079-8
8-215079-0
8-215079-2
8-215079-4
8-215079-6
8-215079-8
9-215079-0
4
3.81
7.1
215079-4
215079-6
6
6.35
9.7
8
8.89
12.2
14.7
17.3
19.8
22.4
24.9
27.4
215079-8
10
12
14
16
18
20
11.43
13.97
16.51
19.05
21.59
24.13
1-215079-0
1-215079-2
1-215079-4
1-215079-6
1-215079-8
2-215079-0
34
Catalog 82012
Revised 4-12
Dimensions are shown for
Dimensions are in inches
and millimeters unless
otherwise specified.
