Light Output Characteristics
1.2
1.1
1.0
0.9
0.8
0.7
0.6
0.5
LUXEON Rebel ES Blue (LXML-PB02)
& Blue (LXML-PB01) Photometric
Green (LXML-PM01) & Cyan (LXML-
PE01) Photometric
LUXEON Rebel ES Royal-Blue (LXML-
PR02) & Royal-Blue (LXML-PR01)
Radiometric
-20
0
20
40
60
80
100
120
140
Thermal Pad Temperature (°C)
Figure 2a. Typical normalized light output vs. junction temperature for LXML-PM01,
LXML-PE01, LXML-PB01, LXML-PB02, LXML-PR01 and LXML-PR02 at test current.
1.75
Red (LXML-PD01 & LXM2-PD01)
Red-Orange (LXML-PH01 & LXM2-PH01)
Amber (LXML-PL01)
1.50
1.25
1.00
0.75
0.50
0.25
0.00
PC Amber (LXM2-PL01)
Far Red (LXML-PF01)
Deep Red (LXM3-PD01
-20
0
20
40
60
80
100
Thermal Pad Temperature (°C)
Figure 2b. Typical normalized light output vs. junction temperature for LXML-PF01, LXM3-PD01,
LXM2-PD01, LXML-PD01, LXM2-PH01, LXML-PH01, LXM2-PL01, LXML-PL01 at test current.
DS68 LUXEON Rebel Color Line Product Datasheet 20171106 ©2017 Lumileds Holding B.V. All rights reserved.
7
