2.7
2.4
2.1
1.8
1.5
1.2
0.9
0.6
0.3
0.0
Blue (LXML-PB01)
Royal Blue (LXML-PR01)
Green (LXML-PM01)
Lime (LXML-PX02)
0
200
400
600
800
1000
Forward Current (mA)
Figure 3d. Relative luminous flux vs. forward current for LXML-PX02,
LXML-PM01, LXML-PB01 and LXML-PR01 at test temperature.
2.00
1.75
1.50
1.25
1.00
0.75
0.50
0.25
0.00
Red (LXM2-PD01) & Red-Orange (LXM2-PH01)
Red (LXML-PD01), Red-Orange (LXML-PH01) & Amber (LXML-PL01)
Far Red (LXML-PF01)
Deep Red (LXM3-PD01)
0
100
200
300
400
500
600
700
800
Forward Current (mA)
Figure 3e. Normalized luminous flux or radiometric power vs. forward current for LXML-PF01, LXM3-PD01, LXM2-PD01,
LXM5-PD01, LXML-PD01, LXM2-PH01, LXM5-PH01, LXML-PH01, LXM5-PL01 and LXML-PL01 at test temperature.
