Data Sheet
ESTW010A0A Series Eighth-Brick Power Modules
November 29, 2011
36–75Vdc Input; 5.0Vdc Output; 10A Output Current
Feature Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature
conditions. See Feature Descriptions for additional information.
Parameter
Device Symbol
Min
Typ
Max
Unit
Remote On/Off Signal Interface
(VIN=VIN, min to VIN, max ; open collector or equivalent,
Signal referenced to VIN- terminal)
Negative Logic: device code suffix “1”
Logic Low = module On, Logic High = module Off
Positive Logic: No device code suffix required
Logic Low = module Off, Logic High = module On
Logic Low - Remote On/Off Current
All
All
All
All
Ion/off
Von/off
Von/off
Ion/off
0.15
0.6
mA
Vdc
Vdc
μA
Logic Low - On/Off Voltage
-0.7
2.4
Logic High Voltage – (Typ = Open Collector)
Logic High maximum allowable leakage current
Turn-On Delay1 and Rise Times
15
25
(IO=IO, max , VIN=VIN, nom, TA = 25oC)
Case 1: Input power is applied for at least 1 second
and then the On/Off input is set from OFF to ON (Tdelay
All
All
Tdelay
―
20
―
msec
msec
= from instant at which On/Off signal is ON until VO
10% of VO, set).
=
Case 2: On/Off input is set to Logic Low (Module
ON) and then input power is applied (Tdelay from
instant at which VIN = VIN, min until Vo=10% of VO,set
Tdelay
―
―
―
150
)
Output voltage Rise time (time for Vo to rise from 10%
of Vo,set to 90% of Vo, set
All
All
All
Trise
15
―
msec
)
Output voltage overshoot – Startup
IO= IO, max; VIN=VIN, min to VIN, max, TA = 25 oC
Prebias Output Load Performance:
―
3
% VO, set
Monotonic
-150
Output Start up characteristic
Back Bias current drawn from output (Module Enabled)
Remote Sense Range
All
All
All
All
All
All
mAdc
% VO, set
% VO, set
Vdc
VSENSE
10
110
7.0
Output Voltage Adjustment range
Output Overvoltage Protection (Co,min=220 μF) 2
Overtemperature Protection – Hiccup Auto Restart
Input Undervoltage Lockout
Turn-on Threshold
80
VO, limit
Tref
6.0
135
OC
VUVLO
32
30
2
34.5
Vdc
Vdc
Vdc
Turn-off Threshold
27.5
1
Hysteresis
1.
2.
The module has an adaptable extended Turn-On Delay interval, Tdelay, of 20mS. The extended Tdelay will occur when the module restarts
following either: 1) the rapid cycling of Vin from normal levels to less than the Input Undervoltage Lockout (which causes module
shutdown), and then back to normal; or 2) toggling the on/off signal from on to off and back to on without removing the input voltage. The
normal Turn-On Delay interval, Tdelay, will occur whenever a module restarts with input voltage removed from the module for the preceding 1
second.
The module requires a minimum of 220 μF external output capacitor to prevent shutdown during no load to full load transients and to avoid
exceeding the OVP maximum limits during startup into open loop fault conditions.
