Micro-D Metal Shell - .050” Contact Spacing
Mounting Hardware Views for Front Panel Mount (for sizes 9-51)
MDM
LOCK
SCREW
.096 ± .005
(2.44 ± 0.13)DIA.
MATING
FACE
#2-56 UNC-2B
RETAINING
CLIP
.170
(4.32) MAX.
.185 (4.70) MAX.
CONNECTOR
SHOWN FOR
REF. ONLY
.408 (10.36)
MAX.
.182 (4.62)
MAX.
PANEL REF. .500
.688 (17.48)
MAX.
A
(12.7)
MAX.
.052
BUSHING
.232 (5.89) MAX.
(1.32) TYP.
#2-56 UNC-2A
.093 (2.36)
#2-56
UNC-2B
THD
Jackpost - (P)
RECOMMENDED
PANEL THICKNESS
.260
(6.60) MAX.
.178 ± .005
(4.52 ± 0.13)
Screw Lock Assembly*
*NOTE Torque value is 2.5 in/lbs max.
B
90° Angle Mounting Bracket
A
B
Description
Part Number
+/-.005 (±0.13)
+/- .010
Screw
322-9500-000
320-9505-000
015-9516-002
015-9516-003
N/A
Jackpost kit
N/A
Mounting Bracket 90° MDM for 9 thru 37 Shell Sizes
Mounting Bracket 90° MDM for 51 Shell Size
.147 (3.73)
.169 (4.29)
.277 (7.82)
.350 (8.89)
NOTES: Screw lock assembly (322-9500-000) can be used for front mounting only. Jackpost kit (320-9505-000) consists of two assmblies, shipped unassmbled.
Jackpost Bushing (for rear panel mounting-for sizes 9-51)
C
HEX IS .135 (3.43)/.115 (2.92) ACROSS FLATS
.105 (2.67)
.100 (2.54)
R TYP.
.170 (4.32)
.185 (4.70)
#2-56 UNC-2B THD
MATING FACE
A
.126 (3.20)
.125 (3.18)
DIA. TYP
B
A
27˚
26˚
TYP
Jackpost diameter within the "A"
dimension is .124/.120 (3.15/3.05).
.500 (12.7)
.480 (12.19)
Plug and Receptacle Dimensions
#2-56 UNC
2A THD
A
B
C
Shell Size
+.004 (0.10)
-.000 (0.00)
+.004 (0.10)
-.000 (0.00)
+_.005 (0.13)
9
.401 (10.19)
.551 (14.00)
.701 (17.81)
.801 (20.34)
.951 (24.16)
1.101 (27.97)
1.051 (26.70)
.252 (6.40)
.252 (6.40)
.252 (6.40)
.252 (6.40)
.252 (6.40)
.252 (6.40)
.295 (7.49)
.565 (14.35)
.715 (18.16)
.865 (21.97)
.965 (24.51)
1.115 (28.34)
1.265 (32.13)
1.215 (30.86)
A
15
21
25
31
37
51
Panel A Thickness
+.005 (0.13)
-.000 (0.00)
Jackpost Kit Number*
3/32 (2.4)
1/16 (1.6)
3/64 (1.2)
1/32 (0.8)
.087 (2.21)
.056 (1.42)
.042 (1.07)
.025 (0.64)
320-9505-007
320-9505-006
320-9505-005
320-9505-004
*A kit consists of 2 jackpost, 2 nuts, 2 washers.
Dimensions shown in mm
Specifications and dimensions subject to change
