Microminiature Circular - .050” Contact Spacing
Shell Dimensions
MIKQ
MIKQ9-7P (Back Panel Mounting)
.043 ± .005
(1.09 ± 0.13)
KEY
.245 (6.22)
DIA. MAX.
.250 ± .010
(6.35 ± 0.25)
WIRE
EXTENSION
LENGTH
.415 ± .010
(10.54 ± 0.25)
INSULATOR
SHELL
.485 (12.32)
MAX.
.570 (14.48)
DIA. MAX.
1/2
HEX-NUT
7/16-28 UNEF-2A
Receptacle
MIKQ9-19P (Back Panel Mounting)
.043 ± .005 (1.09 ± 0.13)
INSULATOR
KEY
.250 ± .010 (6.35 ± 0.25)
.525 ± .010
(13.33 ± 0.25)
.345 (8.76)
DIA. MAX.
+.015
5/8
HEX-NUT
.425
(10.79
.625 ± .010
(15.87 ± 0.25) DIA.
9/16-24 UNEF-2A THREAD
.485 (12.32) MAX.
-.000
+0.30
-0.00
)
Receptacle
MIKQ9-37P (Back Panel Mounting)
.250 ± .010
(6.35 ± 0.25)
.043 ± .005
(1.09 ± 0.13)
.505 MAX.
(12.83 MAX.)
SHELL
.665 MAX.
(16.89) MAX.
.730 ± .010
(18.54 ± 0.25)
INSULATOR
.490 MAX.
3/4-20 UNEF-2A THREAD
13/16 HEX NUT
.885 MAX.
(22.48 MAX.)
(12.45 MAX.)
Receptacle
MIKQ Rear Panel Mounting
Rear Panel Mounting-MIKQ9
A
B
DIA.
A
Shell Size
± .005 (0.13)
.425 (10.76)
.535 (13.58)
.740 (18.78)
MIKQ9-7P
MIKQ9-19P
MIKQ9-37P
.440 (11.18)
.564 (14.33)
.755 (19.17)
B
DIA.
Dimensions shown in mm
Specifications and dimensions subject to change
www.ittcannon.com
64
