Chapter 1. Introduction
MII51001-1.5
The MAX® II family of instant-on, non-volatile CPLDs is based on a
0.18-µm, 6-layer-metal-flash process, with densities from 240 to 2,210
logic elements (LEs) (128 to 2,210 equivalent macrocells) and non-volatile
storage of 8 Kbits. MAX II devices offer high I/O counts, fast
Introduction
performance, and reliable fitting versus other CPLD architectures.
Featuring MultiVolt™ core, a user flash memory (UFM) block, and
enhanced in-system programmability (ISP), MAX II devices are designed
to reduce cost and power while providing programmable solutions for
applications such as bus bridging, I/O expansion, power-on reset (POR)
and sequencing control, and device configuration control.
