MOBILE PENTIUM PROCESSOR WITH MMX™ TECHNOLOGY
Table 24. TCP Key Dimensions
Symbol
N
Description
Leadcount
Dimension
320 leads
W
Tape Width
48.18 ±0.12
L
Site Length
(43.94) reference only
0.40 nominal
0.25 nominal
0.10 ±0.01
T
Test Pad Pitch
Outer Lead Pitch
Outer Lead Width
Package Body Size
Package Height
Die Length
e1
b
D1,E1
A2
24.0 ±0.1
0.597 ±0.030
10.450 +/- 0.015
9.088 +/- 0.015
0.025 mm
DL
DW
LT
Die Width
Lead Thickness
Encap Length
Encap Width
EL
11.053 +/- 0.015
9.691 +/- 0.015
EW
NOTES:
·
·
Dimensions are in millimeters unless otherwise noted.
Dimensions in parentheses are for reference only.
Table 25. Mounted TCP Dimensions
Description
Symbol
A
Dimension
0.75 maximum
29.5 nominal
0.5 g maximum
Package Height
Terminal Dimension
Package Weight
D, E
WT
NOTE:
·
·
Dimensions are in millimeters unless otherwise noted.
Package terminal dimension (lead tip-to-lead tip) assumes the use of a keeper bar.
63
