5 Signal Lists
5.1
Intel® 6700PXH 64-bit PCI Hub Signal List
(Sorted by Signal Name)
Table 5-1. Intel® 6700PXH 64-bit PCI Hub Signal List (Sorted by Signal Name) (Sheet 1 of 16)
Intel® 6700PXH 64-bit PCI Hub
Parallel HP Mux
Pin#
EXP_CLK_N
EXP_CLK_P
EXP_COMP[0]
EXP_COMP[1]
EXP_RXN[0]
EXP_RXN[1]
EXP_RXN[2]
EXP_RXN[3]
EXP_RXN[4]
EXP_RXN[5]
EXP_RXN[6]
EXP_RXN[7]
EXP_RXP[0]
EXP_RXP[1]
EXP_RXP[2]
EXP_RXP[3]
EXP_RXP[4]
EXP_RXP[5]
EXP_RXP[6]
EXP_RXP[7]
EXP_TXN[0]
EXP_TXN[1]
EXP_TXN[2]
EXP_TXN[3]
EXP_TXN[4]
EXP_TXN[5]
EXP_TXN[6]
EXP_TXN[7]
EXP_TXP[0]
C17
C16
E16
B17
F10
D12
B9
C11
H12
D13
A16
E15
G10
E12
C9
C10
G12
C13
A15
E14
E11
D10
A10
B12
G13
B15
D16
F14
F11
