Processor Configuration Registers
B/D/F/Type:
Address Offset:
Reset Value:
Access:
0/1/0–2/PCI
B2–B3h
1001h
RW1C, RO-V, RO
16 bits
Size:
BIOS Optimal Default
0h
Reset
Value
RST/
PWR
Bit
Access
Description
10
RO
0h
Reserved (RSVD)
Negotiated Link Width (NLW)
This field indicates negotiated link width. This field is valid only
when the link is in the L0, L0s, or L1 states (after link width
negotiation is successfully completed).
00h = Reserved
01h = X1
02h = X2
9:4
RO-V
00h
Uncore
04h = X4
08h = X8
10h = X16
All other encodings are reserved.
Current Link Speed (CLS)
This field indicates the negotiated Link speed of the given PCI
Express Link.
The encoding is the binary value of the bit location in the
Supported Link Speeds Vector (in the Link Capabilities 2 register)
that corresponds to the current Link speed.
3:0
RO
0h
For example, a value of 0010b in this field indicates that the
current Link speed is that corresponding to bit 2 in the Supported
Link Speeds Vector, which is 5.0 GT/s.
All other encodings are reserved.
The value in this field is undefined when the Link is not up.
2.6.41
SLOTCAP—Slot Capabilities Register
Note:
PCI Express* Hot-Plug is not supported on the processor.
B/D/F/Type:
Address Offset:
Reset Value:
Access:
0/1/0–2/PCI
B4–B7h
00040000h
RW-O, RO
32 bits
Size:
Reset
Value
RST/
PWR
Bit
Access
Description
Physical Slot Number (PSN)
This field indicates the physical slot number attached to this Port.
31:19
RW-O
0000h
Uncore
BIOS Requirement: This field must be initialized by BIOS to a
value that assigns a slot number that is globally unique within the
chassis.
No Command Completed Support (NCCS)
When set to 1b, this bit indicates that this slot does not generate
software notification when an issued command is completed by
the Hot-Plug Controller. This bit is only permitted to be set to 1b
if the hot-plug capable port is able to accept writes to all fields of
the Slot Control register without delay between successive
writes.
18
17
RO
RO
1b
0b
Uncore
Uncore
Reserved for Electromechanical Interlock Present (EIP)
When set to 1b, this bit indicates that an Electromechanical
Interlock is implemented on the chassis for this slot.
Datasheet, Volume 2
119
