XMC1300
XMC1000 Family
Summary of Features
– Subset of 32-bit Thumb2 instruction set
– High code density with 32-bit performance
– Single cycle 32-bit hardware multiplier
– System timer (SysTick) for Operating System support
– Ultra low power consumption
•
•
Nested Vectored Interrupt Controller (NVIC)
Event Request Unit (ERU) for programmable processing of external and internal
service requests
•
MATH Co-processor (MATH), consists of a CORDIC unit for trigonometric calculation
and a division unit
On-Chip Memories
•
•
•
8 kbytes on-chip ROM
16 kbytes on-chip high-speed SRAM
up to 200 kbytes on-chip Flash program and data memory
Communication Peripherals
•
Two Universal Serial Interface Channels (USIC), usable as UART, double-SPI,
quad-SPI, IIC, IIS and LIN interfaces
Analog Frontend Peripherals
•
A/D Converters, up to 12 channels, includes 2 sample and hold stages and a fast 12-
bit analog to digital converter with adjustable gain
Up to 8 channels of out of range comparators (ORC)
Up to 3 fast analog comparators (ACMP)
•
•
•
Temperature Sensor (TSE)
Industrial Control Peripherals
•
•
•
•
Capture/Compare Units 4 (CCU4) for use as general purpose timers
Capture/Compare Units 8 (CCU8) for motor control and power conversion
Position Interfaces (POSIF) for hall and quadrature encoders and motor positioning
Brightness and Colour Control Unit (BCCU), for LED color and dimming application
System Control
•
•
•
•
Window Watchdog Timer (WDT) for safety sensitive applications
Real Time Clock module with alarm support (RTC)
System Control Unit (SCU) for system configuration and control
Pseudo random number generator (PRNG), provides random data with fast
generation times
Data Sheet
9
V1.3, 2014-02
