XMC1300
XMC1000 Family
Summary of Features
1.3
Device Type Features
The following table lists the available features per device type.
Table 2
Features of XMC1300 Device Types1)
Derivative
ADC channel
ACMP
BCCU
MATH
XMC1301-T016
XMC1302-T016
XMC1301-T038
XMC1302-T038
XMC1301-Q024
XMC1302-Q024
XMC1301-Q040
XMC1302-Q040
6
2
2
3
3
3
3
3
3
-
-
6
1
-
1
-
12
12
8
1
-
1
-
8
1
-
1
-
12
12
1
1
1) Features that are not included in this table are available in all the derivatives
1.4
Chip Identification Number
The Chip Identification Number allows software to identify the marking. It is a 8 bytes
value with the most significant 7 bytes stored in Flash configuration sector 0 (CS0) at
address location : 1000 0F00H (MSB) - 1000 0F1BH (LSB). The least significant byte of
the Chip Identification Number is the value of register DBGROMID.
Table 3
XMC1300 Chip Identification Number
Value
Derivative
Marking
XMC1301-T016F0008
XMC1301-T016F0016
XMC1301-T016X0008
XMC1301-T016X0016
XMC1302-T016X0008
XMC1302-T016X0016
00013032 01CF00FF 00001FF7 0000100F
00000B00 00001000 00003000 101ED083H
AA
00013032 01CF00FF 00001FF7 0000100F
00000B00 00001000 00005000 101ED083H
AA
AA
AA
AA
AA
00013033 01CF00FF 00001FF7 0000100F
00000B00 00001000 00003000 101ED083H
00013033 01CF00FF 00001FF7 0000100F
00000B00 00001000 00005000 101ED083H
00013033 01FF00FF 00001FF7 0000900F
00000B00 00001000 00003000 101ED083H
00013033 01FF00FF 00001FF7 0000900F
00000B00 00001000 00005000 101ED083H
Data Sheet
12
V1.3, 2014-02
Subject to Agreement on the Use of Product Information
