XMC1300
XMC1000 Family
Electrical Parameter
3.2.6
Power Supply Current
The total power supply current defined below consists of a leakage and a switching
component.
Application relevant values are typically lower than those given in the following tables,
and depend on the customer's system operating conditions (e.g. thermal connection or
used application configurations).
Table 15
Power Supply Parameters1)
Symbol
Parameter
Values
Min. Typ.2) Max.
Unit
Note /
Test Condition
Active mode current3)
I
DDPA CC
−
9.2
12
mA
mA
mA
mA
fMCLK = 32 MHz
fPCLK = 64 MHz
−
4
−
fMCLK = 1 MHz
fPCLK = 1 MHz
Sleep mode current
I
I
I
DDPSE CC −
DDPSD CC −
DDPDS CC −
6.6
1.2
−
fMCLK = 32 MHz
fPCLK = 64 MHz
Peripherals clock enabled4)
Sleep mode current
−
fMCLK = 1 MHz
fPCLK = 1 MHz
Peripherals clock disabled5)
Deep Sleep mode current6)
0.24
6
−
−
mA
Wake-up time from Sleep to tSSA CC
−
cycles
Active mode7)
Wake-up time from Deep
Sleep to Active mode8)
tDSA CC
−
280
−
μsec
1) Not all parameters are 100% tested, but are verified by design/characterisation and test correlation.
2) The typical values are measured at TA = + 25 °C and VDDP = 5 V.
3) CPU and all peripherals clock enabled, Flash is in active mode.
4) CPU is sleep, all peripherals clock enabled and Flash is in active mode.
5) CPU is sleep, Flash is powered down and code executed from RAM after wake-up.
6) CPU is sleep, peripherals clock disabled, Flash is powered down and code executed from RAM after wake-up.
7) CPU is sleep, Flash is in active mode during sleep mode.
8) CPU is sleep, Flash is in power down mode during deep sleep mode.
Data Sheet
38
V1.3, 2014-02
