XMC1300
XMC1000 Family
Electrical Parameter
Table 10
Input/Output Characteristics (Operating Conditions apply) (cont’d)
Parameter
Symbol
Limit Values Unit Test Conditions
Min.
Max.
3)
3)
3)
3)
Maximum current into
IMVDD1 SR
–
130
mA
mA
mA
mA
V
DDP (TSSOP16,
VQFN24)
Maximum current into
IMVDD2 SR
–
–
–
260
130
260
V
DDP (TSSOP38,
VQFN40)
Maximum current out of IMVSS1 SR
SS (TSSOP16,
V
VQFN24)
Maximum current out of IMVSS2 SR
V
SS (TSSOP38,
VQFN40)
1) Not subject to production test, verified by design/characterization. Hysteresis is implemented to avoid meta
stable states and switching due to internal ground bounce. It cannot be guaranteed that it suppresses
switching due to external system noise.
2) An additional error current (IINJ) will flow if an overload current flows through an adjacent pin.
3) Not subject to production test, verified by design/characterization.
4) Not subject to production test, verified by design/characterization. However, for applications with strict low
power-down current requirements, it is mandatory that no active voltage source is supplied at any GPIO pin
when VDDP is powered off.
