XC2287 / XC2286 / XC2285
XC2000 Family Derivatives
Preliminary
Electrical Parameters
3)
CLKOUT
HOLD
tc40
tc41
HLDA
tc41
BREQ
1)
tc10/tc14
CSx, RD,
WR(L/H)
2)
tc11/tc12
/tc13/tc15
/tc16
Addr, Data,
BHE
MCT05561
Figure 24
Notes
External Bus Arbitration, Regaining the Bus
1. This is the last chance for BREQ to trigger the indicated regain-sequence.
Even if BREQ is activated earlier, the regain-sequence is initiated by HOLD going
high. Please note that HOLD may also be deactivated without the XC228x requesting
the bus.
2. The control outputs will be resistive high (pull-up) before being driven inactive (ALE
will be low).
3. The next XC228x driven bus cycle may start here.
Data Sheet
103
V0.91, 2007-02
Draft Version
