TLE9879QXA40
Power Management Unit (PMU)
5.3.2
Voltage Regulator 1.5V (VDDC)
This module represents the 1.5 V voltage regulator, which provides the supply for the microcontroller core, the
digital peripherals and other internal analog 1.5 V functions (e.g. ADC2) of the chip. To further reduce the current
consumption of the MCU during Stop Mode the output voltage can be lowered to 0.9 V.
Features
•
•
•
•
•
•
1.5 V low-drop voltage regulator
Overcurrent monitoring and shutdown with MCU signaling (interrupt)
Overvoltage monitoring with MCU signaling (interrupt)
Undervoltage monitoring with MCU signaling (interrupt)
Undervoltage monitoring with reset
Pull Down Current Source at the output for Sleep Mode only (typ. 100 μA)
The output capacitor CVDDC is mandatory to ensure a proper regulator functionality.
VDDC Regulator
VDDP (5V)
VDDC (1.5V)
A
V
CVDDP
CVDDC
I
1.5V LDO
LDO Supervision
1.5V_LDO_block_external.vsd
Figure 6
Module Block Diagram of VDDC Voltage Regulator
