OPTIREG™ SBC TLE9274QXV33
Wake input
10.3
Electrical characteristics
Table 17 Electrical characteristics
Tj = -40°C to +150°C; VS = 5.5 V to 28 V; all voltages with respect to ground, positive current flowing into pin
(unless otherwise specified)
Parameter
Symbol
Values
Typ.
Unit Note or
Test Condition
Number
Min.
Max.
WK input pin characteristics
Wake-up/monitoring VWKth
2
3
4
V
Hysteresis included
P_10.3.1
threshold voltage
Threshold hysteresis
VWKNth,hys 0.1
–
0.7
-3
V
–
P_10.3.2
P_10.3.3
P_10.3.4
WK pin pull-up current IPU_WK
-20
3
-10
10
µA
µA
VWK_IN = 4 V
VWK_IN = 2 V
WK pin pull-down
current
IPD_WK
20
Input leakage current ILK,l
-2
–
2
µA
0 V < VWK_IN < 28 V
SBC Stop or Sleep
mode
P_10.3.5
Timing
1)
Wake-up filter time
tFWK
–
16
–
µs
P_10.3.6
1) Not subject to production test, tolerance defined by internal oscillator tolerance.
Datasheet
75
Rev.2.0
2022-05-06
