TLE9263QX
Overview
Key Features
•
•
•
•
•
•
Very low quiescent current consumption in Stop- and Sleep Mode
Periodic Cyclic Wake in SBC Normal- and Stop Mode
Periodic Cyclic Sense in SBC Normal-, Stop- and Sleep Mode
Low-Drop Voltage Regulator 5V, 250mA
Low-Drop Voltage Regulator 5V, 100mA, protected features for off-board usage
Low-Drop Voltage Regulator, driving an external PNP transistor - 5V in load sharing configuration or 5V/3.3V
in stand-alone configuration, protected features for off-board usage. Current limitation by shunt resistor (up to
350mA with 470mΩ external shunt resistor) in stand-alone configuration
•
High-Speed CAN Transceiver:
–
–
–
fully compliant to ISO11898-2 and ISO11898-5
suitable for chokeless operation up to 500kbps
supporting CAN FD communication up to 2 Mbps
•
•
Two LIN Transceivers LIN 2.2, J2602 with configurable TXD timeout feature and LIN Flash Mode
Fully compliant to “Hardware Requirements for LIN, CAN and FlexRay Interfaces in Automotive Applications”
Revision 1.3, 2012-05-04
•
•
•
Four High-Side Outputs 7Ω typ.
Dedicated supply pin for High-Side Outputs
Two General Purpose High-Voltage In- and Outputs (GPIOs) configurable as add. Fail Outputs, Wake Inputs,
Low-Side switches or High-Side switches
•
•
•
•
•
•
•
•
•
•
•
Three universal High-Voltage Wake Inputs for voltage level monitoring
Alternate High-Voltage Measurement Function, e.g. for battery voltage sensing
Configurable wake-up sources
Reset Output
Configurable timeout and window watchdog
Up to three Fail Outputs (depending on configuration)
Over temperature and short circuit protection feature
Wide supply input voltage and temperature range
Software compatible to all SBC families TLE926x and TLE927x
Green Product (RoHS compliant) & AEC Qualified
PG-VQFN-48 leadless exposed-pad power package with Lead Tip Inspection (LTI) feature to support
Automatic Optical Inspection (AOI)
Data Sheet
6
Rev. 1.1, 2014-09-26
