TLE 6244X
3.7.8.5 Maximum
For a maximum of 10 times during
C
C
C
E
50
mJ
Clamping En- ECU life (load dump with 400ms
ergy at Load and Ri = 2Ω over the load, e.g. 2W
Dump
lamp)
3.7.8.6 Jump Start
Each output 150% of the values of
3.7.8.3.
For a maximum of 10 jump starts
of 2 minutes each during ECU life.
3.7.8.7Singlepulse
I
OUT15, 16 ≤ 0.6A, max 10 000
E
50
mJ
TC ≤ 60°C
pulses
3.8 Power Outputs
1.1A/45V
In case of open input (parallel con-
trol) or missing power supply the
power stage is switched off. Paral-
lel connection of power stages is
possible.
OUT7,8,
OUT17,18
3.8.1 Nominal Cur-
rent
for OUT7, 8, 17, 18
C
C
IOUTi
1.1
A
h
3.8.2 Extended Cur-
rent Range
IOUT7,8,17,18 > 1.1A
Accumulated operating time
100
3.8.3 Maximum
Current
4.5V ≤ UUBatt ≤ 17V for OUT7, 8
4.5V ≤ UUBatt for OUT17,18
(Short Circuit
Shut down
Threshold
and static
current limita-
tion)
TJ = -40°C
TJ = 150°C
B
A
IOUTi
IOUTi
1.2
1.1
2.2
2.0
A
A
U
UBatt > 21V only for OUT7,8
TJ = -40°C
TJ = 150°C
B
A
IOUTi
IOUTi
1.5
1.3
2.5
2.3
A
A
For OUT7, OUT8
Above this limit short circuit to
UBatt is detected. For the duration
of the shutoff delay time tVoff (see
3.8.4) the output current is limited
to approximately this value. If the
short circuit condition is still
present after tVoff, the outputs
OUT7/8 are switched off. An error
is stored after tDiag (see 3.11.4).
The same is true for OUT17
OUT18 if the static current limita-
tion is not enabled.
Final Data Sheet
54
V4.2, 2003-08-29
