TLE 4726
Absolute Maximum Ratings
TA = – 40 to 125 °C
Parameter
Symbol Limit Values Unit Remarks
min.
0
max.
52
6.5
50
1
Supply voltage
Logic supply voltage
Z-current of VL
Output current
Ground current
Logic inputs
VS
VL
V
–
0
V
Z-diode
IL
–
mA
A
–
–
–
IQ
– 1
– 2
– 6
IGND
VIxx
2
A
VL +
V
IXX ; Phase 1, 2;
0.3
Inhibit
R1, R2, oscillator input voltage
Junction temperature
VRX,
VOSC
– 0.3
VL +
0.3
V
–
Tj
Tj
–
–
125
150
°C
°C
–
max. 10,000 h
Storage temperature
Tstg
– 50
125
°C
–
Note: Stresses above those listed here may cause permanent damage to the
device. Exposure to absolute maximum rating conditions for extended
periods may affect device reliability.
Data Sheet
5
1999-09-15
