    SAK-TC399XP-256F300S BC 参数 Datasheet PDF下载

    SAK-TC399XP-256F300S BC图片预览
    型号： SAK-TC399XP-256F300S BC
    PDF下载： 下载PDF文件 查看货源
    内容描述： [Infineon releases its second generation AURIX microcontroller in embedded flash 40 nm technology. It comes back with an increase in performance, memory sizes, connectivity and more scalability to address the new automotive trends and challenges. This family has more than 20 products to provide the most scalable portfolio of safety microcontrol­ler. In terms of performance, the highest end product TC39x offers 6 cores running at 300 MHz and up to 6.9 MBytes embedded RAM, and consuming below 2 W. ]
    分类和应用：
    文件页数/大小： 548 页 / 21256 K
    品牌： INFINEON [ Infineon ]
     浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第441页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第442页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第443页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第444页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第446页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第447页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第448页浏览型号SAK-TC399XP-256F300S BC的Datasheet PDF文件第449页
    TC39x BC/BD-Step
    Electrical SpecificationTemperature Sensor
    3.11
    Temperature Sensor
    Table 3-25 DTS PMS
    Parameter
    Symbol
    Values
    Typ.
    Unit
    Note / Test Condition
    Min.
    Max.
    Measurement time for each
    conversion 1)
    tM CC
    -
    -
    2.7
    ms
    °C
    Measured from cold
    power-on reset release
    Calibration reference accuracy
    T
    CALACC CC -1
    -
    1
    calibration points @
    TJ=-40°C and
    TJ=127°C
    Accuracy over temperature
    range
    T
    T
    NL CC
    SR SR
    -2
    -
    -
    2
    °C
    °C
    TCALACC has to be
    added in addition
    DTS temperature range
    -40
    170
    1) After warm reset tM is not restarted and is measured from last conversion.
    Table 3-26 DTS Core
    Parameter
    Symbol
    Values
    Typ.
    Unit
    Note / Test Condition
    Min.
    Max.
    Measurement time for each
    conversion 1)
    tM CC
    -
    -
    2.7
    ms
    °C
    Measured from cold
    power-on reset release
    Temperature difference
    between on chip temperature
    sensors
    ΔT CC
    -3
    -
    3
    2
    Calibration reference accuracy
    T
    CALACC CC -2
    -
    °C
    calibration points @
    TJ=-40°C and
    TJ=127°C
    Accuracy over temperature
    range
    T
    T
    NL CC
    SR SR
    -2
    -
    -
    2
    °C
    °C
    T
    CALACC has to be
    added in addition
    DTS temperature range
    -40
    170
    1) After warm reset tM is not restarted and is measured from last conversion.
    Data Sheet
    445
    V 1.2, 2021-03
    OPEN MARKET VERSION
