TC39x BC/BD-Step
Pin Definition and Functions: LFBGA-516 Package Variant Pin Configuration
Table 2-19 Port 32 Functions (cont’d)
Ball
Symbol
Ctrl. Buffer
Type
Function
AA20 P32.5
GTM_TIM5_IN5_9
I
SLOW /
PU1 /
VEXT /
ES
General-purpose input
Mux input channel 5 of TIM module 5
Mux input channel 1 of TIM module 4
Mux input channel 5 of TIM module 3
Receive input channel 10
General-purpose output
GTM muxed output
Transmit output
GTM_TIM4_IN1_14
GTM_TIM3_IN5_8
SENT_SENT10C
P32.5
O0
O1
O2
GTM_TOUT140
ASCLIN2_ATX
IOM_MON2_14
IOM_REF2_14
—
Monitor input 2
Reference input 2
O3
O4
O5
O6
Reserved
—
Reserved
—
Reserved
CAN02_TXD
IOM_MON2_7
IOM_REF2_7
—
CAN transmit output node 2
Monitor input 2
Reference input 2
O7
I
Reserved
AB20 P32.6
SLOW /
PU1 /
VEXT /
ES
General-purpose input
Mux input channel 6 of TIM module 5
Mux input channel 4 of TIM module 4
Mux input channel 6 of TIM module 3
CAN receive input node 2
Trigger input
GTM_TIM5_IN6_9
GTM_TIM4_IN4_15
GTM_TIM3_IN6_8
CAN02_RXDC
CBS_TGI4
ASCLIN2_ARXF
ASCLIN6_ARXC
SENT_SENT11C
P32.6
Receive input
Receive input
Receive input channel 11
General-purpose output
GTM muxed output
Reserved
O0
O1
O2
O3
O4
O5
O6
O7
O
GTM_TOUT141
—
—
Reserved
QSPI2_SLSO12
CAN22_TXD
—
Master slave select output
CAN transmit output node 2
Reserved
—
Reserved
CBS_TGO4
Trigger output
