TC39x BC/BD-Step

Pin Definition and Functions: LFBGA-516 Package Variant Pin Configuration

Table 2-18 Port 31 Functions (cont’d)

Ball

Symbol

Ctrl. Buffer

Type

Function

AK18 P31.13

GTM_TIM6_IN5_8

FAST /

PU1 /

VEBU /

General-purpose input

Mux input channel 5 of TIM module 6

Mux input channel 5 of TIM module 5

Data Bus Input

GTM_TIM5_IN5_8

EBU_AD_IN22

P31.13

General-purpose output

GTM muxed output

Reserved

GTM_TOUT187

—

Reserved

—

Reserved

—

Reserved

—

Reserved

—

Reserved

EBU_AD22

Data Bus Output

General-purpose input

Mux input channel 6 of TIM module 6

Mux input channel 6 of TIM module 5

Data Bus Input

AJ19 P31.14

FAST /

PU1 /

VEBU /

GTM_TIM6_IN6_8

GTM_TIM5_IN6_8

EBU_AD_IN18

P31.14

General-purpose output

GTM muxed output

Reserved

GTM_TOUT188

—

Reserved

—

Reserved

—

Reserved

—

Reserved

—

Reserved

EBU_AD18

Data Bus Output

Data Sheet

139

V 1.2, 2021-03

OPEN MARKET VERSION
