TC39x BC/BD-Step

Pin Definition and Functions: LFBGA-516 Package Variant Pin Configuration

Table 2-18 Port 31 Functions (cont’d)

Ball

Symbol

Ctrl. Buffer

Type

Function

AK14 P31.5

GTM_TIM7_IN5_6

FAST /

PU1 /

VEBU /

General-purpose input

Mux input channel 5 of TIM module 7

Mux input channel 5 of TIM module 2

Data Bus Input

GTM_TIM2_IN5_13

EBU_AD_IN23

P31.5

General-purpose output

GTM muxed output

Reserved

GTM_TOUT179

—

Reserved

—

Reserved

—

Reserved

—

Reserved

—

Reserved

EBU_AD23

Data Bus Output

General-purpose input

Mux input channel 6 of TIM module 7

Mux input channel 6 of TIM module 2

Data Bus Input

AJ15 P31.6

FAST /

PU1 /

VEBU /

GTM_TIM7_IN6_6

GTM_TIM2_IN6_12

EBU_AD_IN20

P31.6

General-purpose output

GTM muxed output

Reserved

GTM_TOUT180

—

Reserved

—

Reserved

—

Reserved

—

Reserved

—

Reserved

EBU_AD20

Data Bus Output

Data Sheet

135

V 1.2, 2021-03

OPEN MARKET VERSION
